户内KA系列地砖屏
| 型号 | KA 0125 | KA0126 | KA0129 | KA0139 | KA0148 | KA0152 | KA0162 |
| 像素间距 | 2.5mm | 2.6mm | 2.976mm | 3.91mm | 4.81mm | 5.2mm | 6.25mm |
| LED封装型号 | SMD1415 | SMD1415 | SMD1415 | SMD1921 | SMD1921 | SMD1921 | SMD1921 |
| 像素密度/m²) | 160,000 | 147,456 | 112,896 | 65,536 | 43,264 | 36,864 | 25,600 |
| 模组分辨率 | 100x100 | 96x96 | 84x84 | 64x64 | 52x52 | 48x48 | 40x40 |
| 模组尺寸(WxHxD)(mm) | 250.85x250.85x18 | 250.85x250.85x18 | 249.8x249.8x18 | 248.8x249.8x18 | 249.8x249.8x18 | 248.8x249.8x18 | 249.8x249.8x18 |
| 箱体尺寸(mm) | 502x502x70 | 502x502x70 | 500x500x68 | 500x500x68 | 500x500x68 | 500x500x68 | 500x500x68 |
| 箱体分辨率 | 200x200 | 192×192 | 168x168 | 128×128 | 104×104 | 96x96 | 80×80 |
| 最大/平均功率(W/箱体) | 200/100 | ||||||
| 工作电压 | 100-240V/AC 50-60Hz | ||||||
| 亮度(cd/m²) | 1200 | ||||||
| 刷新率 | 1920-7680Hz | ||||||
| 观看角度 | 150°/150° | ||||||
| 箱体重量(kg) | 11.9 | ||||||
| 承重 | 1500Kg | ||||||
