户内KM系列
| 型号 | KM 0125 | KM 0126 | KM 0129 | KM 0139 | KM 0148 | KM 0152 | KM 0162 |
| 像素间距 | 2.5mm | 2.6mm | 2.976mm | 3.91mm | 4.81mm | 5.2mm | 6.25mm |
| LED封装型号 | 1415/1515(可选配) | 1415/1515(可选配) | 1415/1515(可选配) | 1921 | 1921 | 1921 | 1921 |
| 像素密度/m²) | 160,000 | 147,456 | 112,896 | 65,536 | 43,264 | 36,864 | 25,600 |
| 模组分辨率 | 100x100 | 96x96 | 84x84 | 64x64 | 52x52 | 48x48 | 40x40 |
| 模组尺寸(WxHxD)(mm) | 250.85x250.85x18 | 250.85x250.85x18 | 249.8x249.8x18 | 249.8x249.8x18 | 249.6x249.6x18 | 248.6x249.6x18 | 249.4x249.4x18 |
| 箱体尺寸(mm) | 502x1004x78 | 502x1004x78 | 500x1000x78 | 500x1000x78 | 500x1000x78 | 500x1000x78 | 500x1000x78 |
| 箱体分辨率 | 200x400 | 192×384 | 168x336 | 128×256 | 104×208 | 96x192 | 80×160 |
| 最大/平均功率(W/箱体) | 400/200 | ||||||
| 工作电压 | 100-240V/AC 50-60Hz | ||||||
| 亮度(cd/m²) | 1200 | ||||||
| 刷新率 | 1920-7680Hz | ||||||
| 观看角度 | 150°/150° | ||||||
| 箱体重量(kg) | 21.1 | ||||||
| 承重 | 2000Kg | ||||||
